Henan Huinong Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of biomass hot air furnace in China. With abundant experience, we warmly welcome you to buy durable biomass hot air furnace at low price from our factory. Customized orders are welcome.
Product Specifications
|
Item |
Unit |
Design Value |
|||
|
5LS-60 Biomass Hot Air Furnace |
5LS-90 Biomass Hot Air Furnace |
5LS-120 Biomass Hot Air Furnace |
5LS-150 Biomass Hot Air Furnace |
||
|
Model Name |
/ |
5LS-60 Biomass Hot Air Furnace |
5LS-90 Biomass Hot Air Furnace |
5LS-120 Biomass Hot Air Furnace |
5LS-150 Biomass Hot Air Furnace |
|
Structure Type |
/ |
Integrated type |
Integrated type |
Integrated type |
Integrated type |
|
Overall Dimensions of Hot Air Furnace Body (L × W × H) |
mm |
4120×1960×2500 |
5550×1960×2500 |
6050×2220×2500 |
6750×2220×2500 |
|
Fuel Type |
/ |
Biomass pellets |
Biomass pellets |
Biomass pellets |
Biomass pellets |
|
Combustion Mode |
/ |
Fluidized bed combustion |
Fluidized bed combustion |
Fluidized bed combustion |
Fluidized bed combustion |
|
Feeding Mode |
/ |
Automatic feeding |
Automatic feeding |
Automatic feeding |
Automatic feeding |
|
Ignition Mode |
/ |
Manual ignition |
Manual ignition |
Manual ignition |
Manual ignition |
|
Thermal Power |
MW |
0.735 |
0.935 |
1.483 |
1.753 |
|
Thermal Efficiency |
% |
≥80% |
≥80% |
≥80% |
≥80% |
|
Output Hot Air Temperature |
℃ |
60~130 |
60~130 |
60~130 |
60~130 |
|
Induced Draft Fan Air Volume |
m³/h |
1268~3665 |
1268~3665 |
2317~4970 |
2317~4970 |
|
Induced Draft Fan Power |
kW |
3 |
3 |
4 |
4 |
|
Hot Air Fan Air Volume |
m³/h |
10314~20628 |
21830~43661 |
24866~49732 |
19647~39274,20739~41478 |
|
Hot Air Fan Power |
kW |
15 |
22 |
37 |
30.37 |
|
Air Volume |
m³/h |
3100 (Air supply fan) |
3100 (Air supply fan) |
3100 (Air supply fan) |
3100 (Air supply fan) |
|
Power |
kW |
2.2 (Air supply fan) |
2.2 (Air supply fan) |
2.2 (Air supply fan) |
2.2 (Air supply fan) |
|
Total Matched Power |
kW |
7.19 (Excluding hot air fan) |
7.19 (Excluding hot air fan) |
8.54 (Excluding hot air fan) |
8.54 (Excluding hot air fan) |
Product Benefits
High airflow, high static pressure, and ample heat output
Product Applications
Our Services
FAQ
Q: Who are we?
A: We are a source manufacturer with our own production workshop and R&D team.
Q: Does the equipment support customization?
A: OEM/ODM customization is available for dimensions, heat sources, control systems, production capacity and other aspects.
Q: Why Choose Us?
A: 1).We are Manufacturer of Grain Processing Machinery.
2).100% QC inspection Before Shipment.
3).Our products have been sold to many countries and regions, including Europe, America, Southeast Asia, Africa, and other countries, and have gained a good reputation.
Q: How long is the delivery cycle?
A: Peak Season Lead Time: 1-3 month
Off Season Lead Time: one month
Q: Can we visit the factory?
A: Factory inspections on site are welcome, and reception can be arranged with an advance appointment.
Hot Tags: biomass hot air furnace, China biomass hot air furnace manufacturers, suppliers, factory
