Henan Huinong Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of circular grain dryer in China. With abundant experience, we warmly welcome you to buy durable circular grain dryer at low price from our factory. Customized orders are welcome.
Product Specifications
|
Serial Number |
Project |
Unit |
Design Value |
|
1 |
Model Name |
/ |
5HX-22 Grain Drying Machine |
|
2 |
Structural Type (Continuous/Batch Cycle/Batch Static) |
/ |
Batch Cycle |
|
3 |
Drying method (direct heating/indirect heating) |
/ |
indirect heat |
|
4 |
Drying process (co flow/cross flow/mixed flow/counter flow) |
/ |
downstream |
|
5 |
Dimensions of the dryer body (length x width x height) |
mm |
2600×2400×9500 |
|
6 |
processing capacity |
t/d |
/ |
|
7 |
Precipitation amplitude,% |
/ |
/ |
|
8 |
Batch processing volume |
t |
22 |
|
9 |
Precipitation rate |
%/h |
≥0.5 |
|
10 |
Number of drying sections |
pcs |
1 |
|
11 |
Total height of the Su section |
pcs |
1 |
|
12 |
Total height of the drying section |
mm |
2700 |
|
13 |
Total height of the Su section |
mm |
4100 |
|
14 |
Cooling section height |
mm |
/ |
|
15 |
effective volume |
m³ |
40 |
|
16 |
Hot air temperature range |
℃ |
45~160 |
|
17 |
Number of hot air fans |
pcs |
1 |
|
18 |
Air supply type of hot air blower (positive pressure/negative pressure) |
/ |
negative pressure |
|
19 |
Model name of No.1 hot air blower |
/ |
4-72-6.8A centrifugal fan |
|
20 |
Motor power of No.1 hot air blower |
kw |
7.5 |
|
21 |
Model name of No.2 hot air blower |
/ |
/ |
|
22 |
Motor power of No.2 hot air blower |
kw |
/ |
|
23 |
Motor power of No.3 hot air blower |
kw |
/ |
|
24 |
Number of cooling fans |
pcs |
/ |
|
25 |
Cooling fan model name |
/ |
/ |
|
26 |
Cooling fan motor power |
kw |
/ |
|
27 |
Total power of dryer motor |
kw |
11.7 |
|
28 |
Type of heat source (coal/oil/gas/electricity consumption) |
/ |
fuel |
|
29 |
Equipment model name providing heat source |
/ |
YL-30 Fully Automatic Combustion Machine |
|
30 |
Heat source thermal power (output heat) |
kcal/h |
300000 |
|
31 |
Improve equipment productivity |
t/h |
10~15 |
Four Major Features
Advanced Technology: Incorporates proven drying technology and features a well-designed structure.
Superior Drying Quality: Ensures uniform drying of grains, delivers excellent results, and safeguards grain quality and storage safety.
Applications
The recirculating grain dryer offers a wide range of applications, low drying costs, minimal power requirements, and low thermal energy consumption.
The equipment employs a low-temperature, constant-temperature, full-coverage drying process that relies on clean hot air circulation to achieve comprehensive drying with no dead zones. The entire process is free of pollution and secondary contamination, effectively ensuring grain quality.
The equipment operates with stable performance. Compared to traditional high-temperature dryers, it improves moisture removal efficiency by approximately 30% and significantly reduces grain breakage and loss. After drying, the moisture content is uniformly consistent throughout the grain, making it more suitable for long-term storage. The moisture regain rate is reduced by over 98% compared to high-temperature dryers, making it the optimal equipment for grain drying.
Grains suitable for drying: rice, wheat, corn, soybeans, black rice, buckwheat, etc.
Our Services
Pre-Sales Services
- Equipment Model Selection: We recommend suitable equipment models based on customer needs.
- Customization Services: We design and manufacture products according to customers' specific requirements.
- Technical Training: We provide relevant training for customers' technical staff.
In-Sales Services
- Product Acceptance: We assist customers with factory and on-site product acceptance inspections.
- Solution Support: We assist customers in developing site construction and supporting construction plans.
After-Sales Services
- Installation and Commissioning: Responsible for on-site installation and commissioning of equipment.
- Operational Training: Provide hands-on training to on-site operators.
- On-site Support: After equipment installation is complete, we can deploy 1–2 full-time technical personnel to provide on-site assistance.
- Engineer On-site Visits: Assign a dedicated after-sales engineer to the site to assist customers in resolving various issues.
- Regular Follow-ups: Conduct regular or ad hoc follow-ups via phone or by dispatching dedicated personnel to collect user feedback and suggestions.
FAQ
Q: Who are we?
A: We are a source manufacturer with our own production workshop and R&D team.
Q: Does the equipment support customization?
A: OEM/ODM customization is available for dimensions, heat sources, control systems, production capacity and other aspects.
Q: Why Choose Us?
A：1).We are Manufacturer of Grain Processing Machinery.
2).100% QC inspection Before Shipment.
3).Our products have been sold to many countries and regions, including Europe, America, Southeast Asia, Africa, and other countries, and have gained a good reputation.
Q: How long is the delivery cycle?
A: Peak Season Lead Time: 1-3 month
Off Season Lead Time: one month
Q: Can we visit the factory?
A: Factory inspections on site are welcome, and reception can be arranged with an advance appointment.
